REFERÊNCIA
DIN 13 - PASSO
NORMAL
|
Diâmetro
Nominal Passo |
Rosca
Externa - Classe 6g
|
Rosca
Interna - Classe 6H
|
||||||||||
|
Diâmetro
Maior
|
Diâmetro
Primitivo
|
Diâmetro
Menor
|
Diâmetro
Menor
|
Diâmetro
Primitivo
|
Diâmetro
Maior |
|||||||
|
máx.
|
min.
|
máx.
|
min.
|
máx.
|
min.
|
min.
|
máx.
|
min.
|
máx.
|
min.
|
||
|
M3
- 0,5
|
2,980
|
2,874
|
2,655
|
2,580
|
2,367
|
2,256
|
2,459
|
2,599
|
2,675
|
2,775
|
3,000
|
|
|
M4
- 0,7
|
3,978
|
3,838
|
3,53
|
3,433
|
3,119
|
2,979
|
3,242
|
3,422
|
3,545
|
3,663
|
4,000
|
|
|
M5
- 0,8
|
4,976
|
4,826
|
4,456
|
4,361
|
3,995
|
3,842
|
4,134
|
4,334
|
4,480
|
4,605
|
5,000
|
|
|
M6
- 1
|
5,974
|
5,794
|
5,324
|
5,212
|
4,747
|
4,563
|
4,917
|
5,153
|
5,350
|
5,500
|
6,000
|
|
|
M7
- 1
|
6,974
|
6,794
|
6,324
|
6,212
|
5,747
|
5,563
|
5,917
|
6,153
|
6,350
|
6,500
|
7,000
|
|
|
M8
- 1,25
|
7,972
|
7,760
|
7,160
|
7,042
|
6,438
|
6,230
|
6,647
|
6,912
|
7,188
|
7,348
|
8,000
|
|
|
M9
- 1,25
|
8,972
|
8,760
|
8,160
|
8,042
|
7,438
|
7,230
|
7,647
|
7,912
|
8,188
|
8,348
|
9,000
|
|
|
M10
- 1,5
|
9,968
|
9,732
|
8,994
|
8,862
|
8,128
|
7,888
|
8,376
|
8,676
|
9,026
|
9,206
|
10,000
|
|
|
M12
- 1,75
|
11,966
|
11,701
|
10,829
|
10,679
|
9,819
|
9,543
|
10,106
|
10,441
|
10,863
|
11,063
|
12,000
|
|
|
M14
- 2
|
13,962
|
12,682
|
12,663
|
12,503
|
11,508
|
11,204
|
11,835
|
12,210
|
12,701
|
12,913
|
14,000
|
|
|
M16
- 2
|
15,962
|
15,682
|
14,663
|
14,503
|
13,508
|
13,204
|
13,835
|
14,210
|
14,701
|
14,913
|
16,000
|
|
|
M18
- 2,5
|
17,958
|
17,623
|
16,334
|
16,164
|
14,891
|
14,541
|
15,294
|
15,744
|
16,376
|
16,600
|
18,000
|
|
|
M20
- 2,5
|
19,958
|
19,623
|
18,334
|
18,164
|
16,891
|
16,541
|
17,294
|
17,744
|
18,376
|
18,600
|
20,000
|
|
|
M22
- 2,5
|
21,958
|
21,623
|
20,334
|
20,164
|
18,891
|
18,541
|
19,294
|
19,744
|
20,376
|
20,600
|
22,000
|
|
|
M24
- 3
|
23,952
|
23,577
|
22,003
|
21,803
|
20,271
|
19,855
|
20,752
|
21,252
|
22,051
|
22,316
|
24,000
|
|
|
M27
- 3
|
26,952
|
26,577
|
25,003
|
24,803
|
23,271
|
22,855
|
23,752
|
24,252
|
25,051
|
25,316
|
27,000
|
|
|
M30
- 3,5
|
29,947
|
29,522
|
27,674
|
27,462
|
25,653
|
25,189
|
26,211
|
26,771
|
27,727
|
287,007
|
30,000
|
|
|
M33
- 3,5
|
32,947
|
32,522
|
30,674
|
30,462
|
28,653
|
28,189
|
29,211
|
29,771
|
30,727
|
31,007
|
33,000
|
|
|
M36
- 4
|
35,940
|
35,465
|
33,342
|
33,118
|
31,033
|
30,521
|
31,670
|
32,270
|
33,402
|
33,702
|
36,000
|
|
|
M39
- 4
|
38,940
|
38,465
|
36,342
|
36,118
|
34,033
|
33,521
|
34,670
|
35,270
|
36,402
|
36,702
|
39,000
|
|
|
M42
- 4,5
|
41,937
|
41,437
|
39,014
|
38,778
|
36,416
|
35,856
|
37,129
|
37,799
|
39,077
|
39,392
|
42,000
|
|
|
M45
- 4,5
|
44,937
|
44,437
|
42,014
|
41,778
|
39,416
|
38,856
|
40,19
|
40,799
|
42,077
|
42,392
|
45,000
|
|
|
M48
- 5
|
47,929
|
47,399
|
44,681
|
44,431
|
41,795
|
41,185
|
42,587
|
43,297
|
44,752
|
45,087
|
48,000
|
|
|
M52
- 5
|
51,929
|
51,399
|
48,681
|
48,431
|
45,795
|
45,185
|
46,297
|
47,297
|
48,752
|
49,087
|
52,000
|
|
|
M56
- 5,5
|
55,925
|
55,365
|
52,353
|
52,088
|
49,177
|
48,516
|
50,046
|
50,796
|
52,428
|
52,783
|
56,000
|
|
